Metalens in the visible frequency range#

View this project in Tidy3D Web App.

Introduction#

Here we use Tidy3D to simulate a very large dielectric metalens. We base this example off of the recent paper from Khorasaninejad et al. titled Metalenses at visible wavelengths: Diffraction-limited focusing and subwavelength resolution imaging, which was recently published in Science. In this paper, a 2-dimensional array of dielectric structures is used as a lens to focus transmitted light to a single position directly above the device.

Typically, these structures are simulated by simulating each dielectric unit cell individually to compute a phase and amplitude transmittance for each cell. While this approach makes for an approximation of the overall device performance, it would be useful to be able to simulate the entire device as a whole to capture the entire physics. However, a simulation of this scale requires several hours or days to do with a conventional CPU-based FDTD. With Tidy3D, we are able to complete the entire simulation in about 1 minute!

First, we’ll show a simple approach for computing fields on the focal plane by simply placing a FieldMonitor at the focal plane to record the fields. However, the focal plane is several wavelengths away from the structure, which means that the above setup will involve simulating fields propagating through lots of empty space. Therefore, we will also show how one can instead record the near fields on a large surface just above the structure, and then project them to the focal plane without actually simulating the fields in the empty region in between, leading to a further improvement in the already-impressive simulation speed.

If you are new to the finite-difference time-domain (FDTD) method, we highly recommend going through our FDTD101 tutorials.

Setup#

We first perform basic imports of the packages needed.

[1]:
# standard python imports
import numpy as np
from numpy import random
import matplotlib.pyplot as plt

import tidy3d as td
from tidy3d import web

Define Simulation Parameters#

We now set the basic parameters that define the metalens. The following image (taken from the original paper) define the variables describing the unit cell of the metalens. The angle of each cell (ΞΈ) is chosen for maximum focusing effect. Note that microns are the default spatial unit in Tidy3D.

diagram

[2]:
# 1 nanometer in units of microns (for conversion)
nm = 1e-3

# free space central wavelength
wavelength = 600 * nm

# desired numerical aperture
NA = 0.5

# shape parameters of metalens unit cell (um) (refer to image above and see paper for details)
W = 85 * nm
L = 410 * nm
H = 600 * nm
S = 430 * nm

# space between bottom PML and substrate (-z)
space_below_sub = 1 * wavelength

# thickness of substrate
thickness_sub = 100 * nm

# side length of entire metalens (um)
side_length = 10

# Number of unit cells in each x and y direction (NxN grid)
N = int(side_length / S)
print(f"for diameter of {side_length:.1f} um, have {N} cells per side")
print(f"full metalens has area of {side_length**2:.1f} um^2 and {N*N} total cells")

# Define material properties at 600 nm
n_TiO2 = 2.40
n_SiO2 = 1.46
air = td.Medium(permittivity=1.0)
SiO2 = td.Medium(permittivity=n_SiO2**2)
TiO2 = td.Medium(permittivity=n_TiO2**2)

for diameter of 10.0 um, have 23 cells per side
full metalens has area of 100.0 um^2 and 529 total cells
[3]:
# using the wavelength in microns, one can use td.C_0 (um/s) to get frequency in Hz
# wavelength_meters = wavelength * meters
f0 = td.C_0 / wavelength

# Compute the domain size in x, y (note: round down from side_length)
length_xy = N * S

# focal length given diameter and numerical aperture
f = length_xy / 2 / NA * np.sqrt(1 - NA**2)

# Function describing the theoretical best angle of each box at position (x,y).  see paper for details
def theta(x, y):
    return np.pi / wavelength * (f - np.sqrt(x**2 + y**2 + f**2))


# total domain size in z: (space -> substrate -> unit cell -> 1.7 focal lengths)
length_z = space_below_sub + thickness_sub + H + 1.7 * f

# construct simulation size array
sim_size = (length_xy, length_xy, length_z)

Create Metalens Geometry#

Now we can automatically generate a large metalens structure using these parameters.

We will first create the substrate as a td.Box

Then, we will loop through the x and y coordinates of the lens and create each unit cell as a td.PolySlab

[4]:
# define substrate
substrate = td.Structure(
    geometry=td.Box(
        center=[0, 0, -length_z / 2 + space_below_sub + thickness_sub / 2.0],
        size=[td.inf, td.inf, thickness_sub],
    ),
    medium=SiO2,
)

# define coordinates of each unit cell
centers_x = S * np.arange(N) - length_xy / 2.0 + S / 2.0
centers_y = S * np.arange(N) - length_xy / 2.0 + S / 2.0
center_z = -length_z / 2 + space_below_sub + thickness_sub + H / 2.0

# x, y vertices of box of size (L, W) centered at the origin
vertices_origin = np.array(
    [[+L / 2, +W / 2], [-L / 2, +W / 2], [-L / 2, -W / 2], [+L / 2, -W / 2]]
)


xs, ys = np.meshgrid(centers_x, centers_y, indexing="ij")
xs = xs.flatten()
ys = ys.flatten()

angles = theta(xs, ys)

# 2x2 rotation matrix angle `angle` with respect to x axis
rotation_matrix = np.array(
    [[+np.cos(angles), -np.sin(angles)], [+np.sin(angles), +np.cos(angles)]]
)

# rotate the origin vertices by this angle
vertices_rotated = np.einsum("ij, jkn -> nik", vertices_origin, rotation_matrix)

# shift the rotated vertices to be centered at (xs, ys)
vertices_shifted = vertices_rotated + np.stack([xs, ys], axis=-1)[:, None, :]

metalens_geometry = []
for vertices in vertices_shifted:
    # create a tidy3D PolySlab with these rotated and shifted vertices and thickness `H`
    metalens_geometry.append(
        td.PolySlab(
            vertices=vertices.tolist(),
            slab_bounds=(center_z - H / 2, center_z + H / 2),
            axis=2,
        ),
    )

metalens = td.Structure(
    geometry=td.GeometryGroup(geometries=metalens_geometry), medium=TiO2
)

Define grid specification#

We define the grid based on the properties of the geometry. The metalens is quasi-periodic in x and y, in that we have clearly defined unit cells, but each is slightly modified from its neighbors. Such structures are best resolved with a grid that matches the periodicity, which is why we use a uniform grid in x and y. In z, we use the automatic nonuniform grid that will place a higher grid density around the metalens region, and a lower one in the air region away from the metalens. To speed up the auto meshing in the region with the pillars, we put an override box in the grid specification.

[5]:
# steps per unit cell along x and y
grids_per_unit_length = 20

# uniform mesh in x and y
grid_x = td.UniformGrid(dl=S / grids_per_unit_length)
grid_y = td.UniformGrid(dl=S / grids_per_unit_length)

# in z, use an automatic nonuniform mesh with the wavelength being the "unit length"
grid_z = td.AutoGrid(min_steps_per_wvl=grids_per_unit_length)

# we need to supply the wavelength because of the automatic mesh in z
grid_spec = td.GridSpec(
    wavelength=wavelength, grid_x=grid_x, grid_y=grid_y, grid_z=grid_z
)

# put an override box over the pillars to avoid parsing a large amount of structures in the mesher
grid_spec = grid_spec.copy(
    update=dict(
        override_structures=[
            td.Structure(
                geometry=td.Box.from_bounds(
                    rmin=(-td.inf, -td.inf, -length_z / 2 + space_below_sub),
                    rmax=(td.inf, td.inf, center_z + H / 2),
                ),
                medium=TiO2,
            )
        ]
    )
)

Define Sources#

Now we define the incident fields. We simply use a normally incident plane wave with Guassian time dependence centered at our central frequency. For more details, see the plane wave source documentation and the gaussian source documentation

[6]:
# Bandwidth in Hz
fwidth = f0 / 10.0

# time dependence of source
gaussian = td.GaussianPulse(freq0=f0, fwidth=fwidth, phase=0)

source = td.PlaneWave(
    source_time=gaussian,
    size=(td.inf, td.inf, 0),
    center=(0, 0, -length_z / 2 + space_below_sub / 10.0),
    direction="+",
    pol_angle=0,
)

run_time = 50 / fwidth

Define Monitors#

Now we define the monitors that measure field output from the FDTD simulation. For simplicity, we use measure the fields at the central frequency. We’ll get the fields at the following locations:

  • The y=0 cross section

  • The x=0 cross section

  • The z=f cross section at the focal plane

  • The central axis, along x=y=0

For more details on defining monitors, see the field monitor documentation.

[7]:
# To decrease the amount of data stored, only store the E field in 2D monitors
fields = ["Ex", "Ey", "Ez"]

# get fields along x=y=0 axis
monitor_center = td.FieldMonitor(
    center=[0.0, 0.0, 0], size=[0, 0, td.inf], freqs=[f0], name="center"
)

# get the fields at a few cross-sectional planes
monitor_xz = td.FieldMonitor(
    center=[0.0, 0.0, 0.0],
    size=[td.inf, 0.0, td.inf],
    freqs=[f0],
    name="xz",
    fields=fields,
)

monitor_yz = td.FieldMonitor(
    center=[0.0, 0.0, 0.0],
    size=[0.0, td.inf, td.inf],
    freqs=[f0],
    name="yz",
    fields=fields,
)

monitor_xy = td.FieldMonitor(
    center=[0.0, 0.0, center_z + H / 2 + f],
    size=[td.inf, td.inf, 0],
    freqs=[f0],
    name="focal_plane",
    fields=fields,
)

# put them into a single list
monitors = [monitor_center, monitor_xz, monitor_yz, monitor_xy]

[15:22:24] WARNING: Default value for the field monitor           monitor.py:261
           'colocate' setting has changed to 'True' in Tidy3D
           2.4.0. All field components will be colocated to the
           grid boundaries. Set to 'False' to get the raw fields
           on the Yee grid instead.
           WARNING: Default value for the field monitor           monitor.py:261
           'colocate' setting has changed to 'True' in Tidy3D
           2.4.0. All field components will be colocated to the
           grid boundaries. Set to 'False' to get the raw fields
           on the Yee grid instead.
           WARNING: Default value for the field monitor           monitor.py:261
           'colocate' setting has changed to 'True' in Tidy3D
           2.4.0. All field components will be colocated to the
           grid boundaries. Set to 'False' to get the raw fields
           on the Yee grid instead.
           WARNING: Default value for the field monitor           monitor.py:261
           'colocate' setting has changed to 'True' in Tidy3D
           2.4.0. All field components will be colocated to the
           grid boundaries. Set to 'False' to get the raw fields
           on the Yee grid instead.

Create Simulation#

Now we can put everything together and define a Simulation object to be run.

We get a number of warnings about structures being too close to the PML. In FDTD simulations, this can result in instability, as PML are absorbing for propagating fields, but can be amplifying for evanescent fields. This particular simulation runs without any issues even with PML on the sides, but it is best to heed these warnings to avoid problems. There are two ways that we can fix the simulation: one is to just put some space between the last of the metalens boxes and the PML. The other is to use adiabatic absorbers on the sides, which are always stable. The only downside of the absorbers is that they are slightly thicker than the PML, making the overall simulation size slighlty larger. This is why we only put them along x and y, while we leave the PML in z.

[8]:
sim = td.Simulation(
    size=sim_size,
    grid_spec=grid_spec,
    structures=[substrate, metalens],
    sources=[source],
    monitors=monitors,
    run_time=run_time,
    boundary_spec=td.BoundarySpec(
        x=td.Boundary.absorber(), y=td.Boundary.absorber(), z=td.Boundary.pml()
    ),
)

           WARNING: Override structures take no effect along    grid_spec.py:558
           x-axis. If intending to apply override structures to
           this axis, use 'AutoGrid'.
           WARNING: Override structures take no effect along    grid_spec.py:558
           y-axis. If intending to apply override structures to
           this axis, use 'AutoGrid'.

The warnings are just letting us know that we are using uniform grid along x and y (per our spec) even though the override structures have some extent in these dimensions. We can ignore as this is intended.

Visualize Geometry#

Lets take a look and make sure everything is defined properly.

[9]:
fig, (ax1, ax2, ax3) = plt.subplots(1, 3, figsize=(14, 6))

sim.plot(x=0.1, ax=ax1)
sim.plot(y=0.1, ax=ax2)
sim.plot(z=-length_z / 2 + space_below_sub + thickness_sub + H / 2, ax=ax3)
plt.show()

../_images/notebooks_Metalens_19_0.png

To have a better visualization, we can also plot the simulation in 3D.

[10]:
sim.plot_3d()
